HDMI 4K 3D Audio Extractor (Splitter)

描述





---

HDMI 4K 3D Audio Extractor (Splitter)
HDMI 4K 3D 音頻分離器

This HDMI audio splitter lets you connect the source device to a display device, and simultaneously separate the digital audio from the HDMI signal to the SPDIF Fiber output or 3.5mm Audio Output

Specification :
[HDMI] HDCP 1.4 / HDMI 1.4b
[Resolution] 4K 30Hz (Max)
[Audio Output] SPDIF + 3.5mm Audio Output

[HDMI Bandwidth] Max 340MHz
[HDMI Baud Rate] Max 10.2Gbps
[Input / Output TMDS Signal] 0.5-1.5Vp-p (TTL)
[Input / Output DDC Signal] 5Vp-p (TTL)
[Size] 58 x 53 x 21.9cm
[Weight] 61grams

* Specification is subjected to change without prior notice

---

HDMI 4K 3D 音頻分離器
HDMI 4K 3D Audio Extractor (Splitter)

這款 HDMI 音頻分離器可連接到一台顯示設備上, 同時還可以同步分離出 HDMI 信號中的數字音頻到 SPDIF 光纖 / 3.5mm 輸出

規格 :
[HDMI] HDCP 1.4 / HDMI 1.4b
[解像度] 4K 30Hz (最高)
[HDMI 頻寬] 最高 340MHz
[HDMI 波特率] 最高 10.2Gbps
[TMDS 信號] 0.5-1.5Vp-p (TTL)
[DDC 信號] 5Vp-p (TTL)
[DAC 採樣頻率] 32-192KHz
[尺寸] 58 x 53 x 21.9cm
[重量] 61grams

* 以上資料僅供參考用, 以產品實際為準備!
